EMT swagelok two ferrule design fittings terminal joint npt bsp male tube connect 90 degree elbow union
YIMIANTE INSTRUMENT FITTINGS
1/8 in TO 2 in , 2 mm to 38 mm
ASTM , ASME , SA , EN
COMPRESSION MALE CONNECTOR
5 PCS AVAILABLE IF WE HAVE STOCK , 100 FOR CUSTOM PRODUCE
DNV GL , ABS , CCS , LR , TUV , ISO9001
30 WORKING DAYS
EXW , FOB , CIF , DDU
30% DEPOSIT , 70% BALANCE BEFORE SHIPPING
PP BAG + WATERPROOF CARTON , EXPORT WOOD BOX
BY AIR , EXPRESS , RAILWAY , SEA ALL AVAILABLE
Stainless steel Compression tube connector, double ferrule female tube fitting
1). Available in tube sizes from 1/16 to 2 in. and 2 to 50 mm
2). nominal pressure:up to 6000 psi
3). applicable temperature:150-400oC
4). applicable medium:oil, water,gas and other corrosive or non-corrosive medium
5). the material for manufacture:20#,1Cr18Ni9Ti, ss 304, 306,316L, carbon steel, brass, etc
6). the demands for fitting pipes:ø4--ø42
7). cone thread:NPT/Z, NPSM, BSPT/R, BSP/G, JIC.DIN, etc.
8). safe, reliable and leak-proof connection, easy installation and sufficient pull-up, no torque transmittion
9). specified specification available upon request
1.Live-loaded, two-ferrule design.
2.Easy to install.
3.No torque is transmitted to tubing during installation.
4.Swagelok gap inspection gauge ensures sufficient pull-up upon initial installation.
1.How can I put the order ? You should send the inqury to our sales to confirm the type ,quantity , price and shipping cost , then make the contract on Alibaba or we can make PI to you . 2.What are your payment term ? Payment <1000usd , full payment in advance , Payment ≧1000USD , 30% deposit, 70% balance before delivery. we will show you photos of the product and packaging when products finished . 3.Can you provide the free sample ? Yes, We provide free samples, you pay the shipping cost . 4.Do you provide OEM service ? Yes , sure ,we are famous brand in China, we have professional team to provide the tenical support for you . 5.What if I don’t have the drawings ? Our engineer will make the drawings according your photos or information . 6.What is your MOQ? MOQ one is available if we have stocks. 7.Can you print our logos on the parts ? Yes , sure , we can provide you laser printing logos and engrave logos . 8.What is your shipping method ? According the goods scale , we can provide express , air shipping and sea shipping , if you have shipping forwarder in China , we can do EXW and delivery the goods to them. If you have DHL account , we can express goods directly , and pay the cost by the account . 9.Can I visit your facotry ? Yes , sure , you can talk the your visit schedule carefully with our sales in advance , we will arrange accordingly
Contact us if you need more details on Swagelok Compression Fitting. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Tube Union Pipe connection
、90 Degree Union Elbow. If these products fail to match your need, please contact us and we would like to provide relevant information.
Product Categories : Tube Fittings
